Golf-IV (MotoMeter 93C56)

Top  Previous  Next

VW  Golf-IV



Original transponder

MEGAMOS-48

Allowed transponder

MEGAMOS-48

Data location

B58813 (93C56 x 16), 93LC56

No. of  keys

8



Caution: After programming the immo LED on a dashboard will blink, but engine starts normally. If  the blinking LED is undesirable, do not use the keymaker;

instead of it, extract the Login from the 24C02 eeprom and learn keys via a diagnostic.



V1

vw_golf_mmet9356



V2

vw_mmeter_9356V2
